1. Simple Introduction
HBS-62.5 digital display small load Brinell hardness tester is a high-tech product of opto-mechatronics. The machine is novel in design, has good reliability, operability and intuitiveness. It is a new type of cloth using precision mechanical technology and photoelectric technology. Test instrument. The machine uses computer software programming, optical measurement system. Through the soft key input, you can choose different head and force value measurement, can adjust the strength of the measuring light source, can choose the holding time, can display the head diameter, test force, measuring range, screen direct reading on the LCD display. The hardness value is simple and easy to check the table. It is easy to use and has higher measurement accuracy due to the use of a rotary encoder. Since the Brinell hardness test uses a large pressure, a large ball diameter and a large indentation diameter, it is suitable for hardness measurement of a large-grain metal material. Such as cast iron, non-ferrous metals and their alloys, after various annealing and quenching and tempering treatments, and most of the steels supplied by the factory, the instrument uses a relatively small part of the Brinell hardness value, so it is especially suitable for softer metals. Such as pure aluminum, copper, lead, tin, zinc and other alloys, the hardness measured is accurate. Hardness has high measurement accuracy, so reproducibility and representativeness

Main features and features:
1, 4 inch large screen LCD display, menu structure,
2, the test process is automated, easy to operate
3, high-definition optical system Light source brightness can be adjusted in 20 levels.
4, with hardness value conversion function, hardness up and down tolerance judgment.
5, diagonal length D1 and D2 encoder input, reducing human error.
6, test results and data processing, can be output through the printer.
7. The shell is cast once, the structure is stable and not deformed, and it can work in a harsh environment;
8. The surface is treated with automobile paint, which has strong scratching ability and is still bright and new for many years;

Main use and scope of use:
1. Suitable for hardness test with large grain metal materials, which can reflect the comprehensive performance of materials;
2, cast iron, steel, non-ferrous metals, especially for softer metals, such as pure aluminum, lead, tin, etc.

2. Technical Parameters

Product number	HBS-62.5
Test force	1, 5, 10, 15.625, 30, 62.5kgf
display	5-digit hardness value, 4-digit diagonal length (D1, D2),
Test force retention time (s)	Hold time, test times, average, standard deviation, return
Load control	1~99
Conversion ruler	Automatic (load/hold/unload)
Minimum unit of measure	Rockwell, Surface Rockwell, Vickers
Total magnification	0. 25μm (subject to the objective lens selected)
	Objective lens: Observe or measure 5X measurement 10X (special objective lens please customize)
Data output	Total magnification: 50X 100X
Maximum size of test piece	Built-in printer
Indenter center to inner wall	Maximum height 165mm
Executive standard	130mm
power supply	Accuracy meets GB231.2, ISO6506-2 and ASTME10
Instrument weight	AC220V±5%, 50~60Hz
Standard accessories	About 45kg
