XJL-630M PVC,MPP,Power pipe,Bellows Pipes, Plastics Pipes Falling Mass Impact Testing Machine
NO:Touch Screen, PVC,MPP,Power pipe,Bellows Pipes, Plastics Pipes sample diameter range: Φ10mm-Φ450mm
Share With:
We"re here to help:
Easy ways to get the answers you need. Send E-mail WhatsAPP/Wechat
+86-15254140530
Easy ways to get the answers you need. Send E-mail WhatsAPP/Wechat
+86-15254140530
1. Functions：
It is used for the plastic pipe, board and goods to do the impact test , to praise the materials resistant outside force impact performance. The machine controlling parts adopt the numerical control technique. It can number preset and display the impact height, automatic return to zero, rising hammer, dropping hammer, impact and can effectively prevent the twice impacting. It adopts the distyle structure, the structure is compact, energy lost is small, and testing speed is quick.
2. Standards-compliant：
ISO 3127 Thermoplastics pipes. Determination of resistance to external blows.
BS EN1411 Plastics piping and ducting systems-Thermoplastics pipes - Determination of resistance
BS EN744 Plastics piping and ducting systems Thermoplastics pipes Test method for resistance to external blows by the round-the-clock method
3. Technical Parameters
Impact height: 0-2000mm,±2mm
Overall dimensions: L730mm×W700mm×H3600 mm
Energy losses: 0.25%
Masses of strikers: 0.25-15kg, permissible tolerance shall be ±0.5%
Nose and masses of striker: depending on customers standards
Rising speed: 12m/min
Anti-rebound catching rate: 100%
Test specimen: Φ10mm-Φ630mm
Weight：300kg
It is used for the plastic pipe, board and goods to do the impact test , to praise the materials resistant outside force impact performance. The machine controlling parts adopt the numerical control technique. It can number preset and display the impact height, automatic return to zero, rising hammer, dropping hammer, impact and can effectively prevent the twice impacting. It adopts the distyle structure, the structure is compact, energy lost is small, and testing speed is quick.
2. Standards-compliant：
ISO 3127 Thermoplastics pipes. Determination of resistance to external blows.
BS EN1411 Plastics piping and ducting systems-Thermoplastics pipes - Determination of resistance
BS EN744 Plastics piping and ducting systems Thermoplastics pipes Test method for resistance to external blows by the round-the-clock method
3. Technical Parameters
Impact height: 0-2000mm,±2mm
Overall dimensions: L730mm×W700mm×H3600 mm
Energy losses: 0.25%
Masses of strikers: 0.25-15kg, permissible tolerance shall be ±0.5%
Nose and masses of striker: depending on customers standards
Rising speed: 12m/min
Anti-rebound catching rate: 100%
Test specimen: Φ10mm-Φ630mm
Weight：300kg
